Alobar holoprosencephaly, proboscis, cyclopia

Marcos Antonio Velasco Sanchez, MD; Candelario Conda Moreno, MD; Andres Zurita Zurita, MD; Hilario Bibiano Pano, MD; Javier Cabrera Garcia, MD

Unidad Obstetrica Quirurgica, Instituto Mexicano De Diagnostico Por Imagen, Hospital General S.S.A. Acapulco Guerrero, Mexico. Facultad De medicina, Division De Posgrado De La Universidad Autonoma de Guerrero, Mexico.

Introduction

Alobar holoprosencephaly is a most severe form of holoprosencephaly characterized by the fused cerebral hemispheres, fused thalami and single primitive ventricle. It can be accompanied by midline facial abnormalities such as cyclopia and proboscis.

Case report

The following images present a case of alobar holoprosencephaly with proboscis and cyclopia. The following ultrasound findings were diagnosed during the ultrasound scan of the 29-year-old woman at 27-week of pregnancy.

Image 1,2: Images show alobar holoprosencephaly.

Holoprosen_Sanchez1
Holoprosen_Sanchez2

Image 3,4: Image 3 shows cyclopia, indicated by arrow; arrows on image 4 indicate proboscis.

Holoprosen_Sanchez3
Holoprosen_Sanchez4

Image 5,6: Image 5 presents a 3D view of proboscis and image 6 of cyclopia.

Holoprosen_Sanchez5
Holoprosen_Sanchez6

Video 1,2: Videos show 2D and 3D view of the fetal face with apparent midline facial abnormalities; proboscis and cyclopia.

Image 7: Image shows the head of the neonate with midfacial abnormalities.

Holoprosen_Sanchez7
